GE VERNOVA | TRANSMISSION AND SUB-TRANSMISSION FEEDER PROTECTION SYSTEM | MICOM AGILE P140 SERIES (P141/P142/P143/P145)

Part of the MiCOM P40 platform, the Agile P14x feeder management relays provide an integrated solution for the complete protection, control and monitoring of overhead lines and underground cables, covering all distribution and transmission voltage levels. Providing all essential information to efficiently maintain complex power systems and their components, the P14x relay family is user-friendly and highly flexible, allowing application on any electrical network. The MiCOM Agile P14x is an advanced feeder management relay platform with overcurrent and earth fault protection, as well as autoreclose and a full suite of protection, control and monitoring functions. The relay can also be used as high impedance busbar with full scheme supervision. The platform also provides main or back-up protection for MV/HV, solidly earthed, impedance earthed, Petersen coil earthed and isolated neutral systems.

Application

  • 1 A and 5 A in the same relay
  • Programmable function keys and LEDs (P145)
  • Customisable menus
  • Control of up to 9 switchgear elements
  • Harsh environmental coating as standard

Key Benefits

  • Full feeder management with efficient monitoring, control, recording and digital communications
  • Supports all major digital control system protocols, easing integration into DCS, SCADA and engineering workstations
  • Fast simple and reliable busbar protection as an alternative application: Numerical single-box solution with full scheme supervision
  • Harsh environment protection extends the life of the product
  • No internal batteries in GE Vernova-branded models – removes a maintenance item and eases air-freight logistics
  • Advanced binary inputs comply with the harshest norms for surge withstand, plus the ESI 48-4 EB2 standard. Spurious wiring pickup is eliminated without the use of interposing relays, external resistors or time delays. Battery/wiring faults, switching noise, and induction from long parallel circuits are tolerated without misoperation.
  • NERC CIP cybersecurity including role-based access control (RBAC), RADIUS and SysLog

Agile P14x Models Available

  • P141 Feeder management IED
  • P142 Feeder management IED with autoreclose
  • P143 Feeder management IED with autoreclose and synchronizing.
  • P145 Feeder management IED with autoreclose, synchronizing and function keys


GE VERNOVA | TRANSMISSION AND SUB-TRANSMISSION FEEDER PROTECTION SYSTEM | MICOM AGILE P140 SERIES (P141/P142/P143/P145)

Advanced Communications

  • Wide range of supported protocols Courier/K-Bus, Modbus, IEC 60870-5- 103, DNP 3.0 (RS485 or Ethernet) and IEC 61850
  • Latest communication protocol implementation with IEEE 1588 precision-time (PTP)
  • Software switchable between IEC 61850 Ed. 1 / Ed. 2 support
  • Redundant communications with zero downtime using optional PRP/HSR protocols
