theMova S360-100 DE WH

theMova S360-100 DE WH

Presence and motion detectors Indoor detectors

Description


  • Passive infra-red motion detector for ceiling installation in false ceilings
  • Circular detection area 360°, up to Ø 8 m (50 m2) at mounting height 3 m
  • 1 channel light (Relay 230 V)
  • Automatic motion and brightness-dependent control for lighting
  • Mixed light measurement
  • Operation as fully automatic device
  • Brightness switching value configurable, teach-in function
  • Pulse function for staircase light time switch
  • Time delay configurable
  • Detection sensitivity configurable
  • Test mode for checking function and detection area
  • Ready for immediate use due to factory presetting (Brightness switching value 300 lux, Time delay 10 min.)
  • One of these optional remote controls is required for changing the values and attitudes:
  • Management remote control SendoPro
  • Installation remote control theSenda P
  • Optional user remote control: theSenda S


Technical data


theMova S360-100 DE WH
theMova S360-100 DE WH

Connection example


theMova S360-100 DE WH

Detection range for planning applications


theMova S360-100 DE WH

Scale drawings


theMova S360-100 DE WH

Accessories


theMova S360-100 DE WH
