GE VERNOVA | DISTRIBUTION & INDUSTRY FEEDER PROTECTION SYSTEM | MULTILIN 350

The Multilin 350 is a member of the Multilin 3 Series protective relay platform and has been designed for the protection, control and management of feeders or related applications as a primary or backup protection device. This cost-effective protective device is used to perform advanced feeder protection, control and monitoring for low, medium and high voltage applications. The 350 also offers enhanced features such as integrated arc flash protection, metering, monitoring and diagnostics, preventative maintenance, advanced communications and security. The 350 protection relay chassis used with a draw out relay is available separately, for use as a partial replacement or in test environments. The draw out relay with no chassis is also available to order as a spare unit.

Overview
Protection
Communication

Applications

Primary protection and control for medium and high voltage utility and industrial overhead or cable feeder applications
Protection of small and medium size distribution transformers
Back-up protection of various HV applications
Capacitor bank protection
Advanced control applications including Cold Load Pickup, multi-shot recloser and multiple setting groups

Key Benefits

Cost-effective and flexible protection and control
Field-proven algorithms and reliable protection to avoid unwanted trips or under-protection
Ease of use and standardization with one-step setup and universal CT inputs
Environmental monitoring system to monitor operating conditions and plan preventative maintenance
Advanced power system and switchgear diagnostics
Flexible communications with multiple ports and protocols allowing seamless integration
Arc flash mitigation via zone inter-tripping, flex curves and multiple elements and setting groups
Integrated arc flash detection using light sensors supervised by over current to reduce incident energy and damage
Powerful Security and hierarchical password control for centralized management
Application flexibility with the use of programmable logic elements
Drawout design simplifies, commissioning and maintenance, thereby increasing process uptime
Increased network availability with zero failover time through IEC® 62439-3 PRP and HSR support
Precise time synchronization through IEEE® 1588 (Precise Time Protocol (PTP)) support
Robust design exceeding industry standards, with Automotive Grade components and advanced testing procedures such as accelerated life cycle testing
Simplified migration of legacy MII Family relays to the 3 Series platform
Intuitive configuration software and user-friendly logic configuration tool

Key Features

Front USB and rear serial, Ethernet, fiber and dual port options for seamless redundancy (IEC 62439-3, PRP & HSR)
Multiple communication protocols supporting industry leading standards

Advanced Communications

The 350 incorporates the latest communication technologies, making it the easiest and the most flexible feeder protection relay for use and integration into new and existing infrastructures. The 350 relay provides the user with one front USB and one rear RS485 communication port. Also available with the 350 is a rear communication port with Ethernet Fiber and Copper. For configurations requiring PRP and HSR redundancy protocols, the 350 provides two rear Fiber ports. Through the use of these ports, continuous monitoring and control from a remote computer, SCADA system or PLC is possible.

The 350 provides optional Parallel Redundancy Protocol (PRP) and High Availability Seamless Ring (HSR) according to the IEC 62439-3 standard that defines two protocols to increase network availability by reducing failover time to zero. Both ports are capable of simultaneously supporting the following protocols: Modbus TCP/ IP, IEC 61850, DNP3 or IEC 60870-5-104, IEEE 1588, SNTP and OPC-UA.

Link Loss Alert (LLA) function detects any issue with one port and switch to the other one in case of failure.

The 350 supports popular industry-leading standard protocols enabling easy, direct integration into electrical SCADA and HMI systems. The protocols supported by the 350 include,
